The ART USB Mix Three Channel Microphone, Instrument, and Line Mixer / Computer Interface is a compact versatile audio interface for your computer that converts analog signals from a variety of audio sources to USB Audio. The USB Mix provides a great starting point for personal home studio recording or for anyone wanting to do mobile location recording.
Features:
โข USB powered, no external power supply needed when used with a computer
โข Balanced XLR or unbalanced -inch Instrument inputs with switchable impedance
โข Switchable low noise +48V phantom power
โข Balanced -inch TRS inputs for stereo or mono line-level sources
โข -inch TRS output jacks work with balanced or unbalanced lines
โข Stereo -inch TRS headphone jack with independent level control for output monitoring
โข Independent controls for both sets of inputs, main output, and headphone monitor
โข Green/Red LED signal/clip indicator
โข Switchable assignment of USB playback to channels 2 and 3
โข USB 2.0 compliant
โข USB cable, AC adapter, and Audacity recording software included
Specifications:
โข Input Connections: XLR balanced / 1/4″ unbalanced “Combo” jack (ch1 input)1/4″ balanced or unbalanced (Ch2-Ch3 inputs)
โข Output Cannections: 1/4″ TRS balanced (Main Mix outputs)1/4″ TRS stereo (Monitor output)
โข Input Impedance: 240k Ohms (Inst-HiZ), 20k Ohms (Line) (Ch 1, Ch2-Ch3 1/4″ inputs)> 4k Ohms (Ch1 XLR input)
โข Output Impedance: 90 dB typical (Ref 0 dBu)
โข Equivalent Input Noise: -120 dBu typical (XLR balanced, max gain), -100 dBu typical (1/4″)
โข Maximum Input Level: +4dBu (XLR input), +14dBu (1/4″ input)
โข Maximum Output Level: +14dBu (Main Mix Outputs), +13dBu (Monitor output)
โข Maximum Gain (In to Main Out): +53dB (XLR), +32dB (1/4″) Ch1 input+10dB (1/4″) (Ch2-Ch3 inputs)
โข Maximum Gain (In to USB): +44dB (XLR), +23dB (1/4″) (Ch1 input)+1dB (1/4″) (Ch2-Ch3 inputs)
โข Maximum Gain (USB to Out): +14dB (Main Mix outputs), +13dB (Monitor output)
โข Phantom Power: Switch selectable, +48V DC, filtered, current limited
โข A/D-D/A: 16 Bit, 44.1 kHz or 48 kHz, USB selectable from computer0.4 ms A/D latency @ 44.1 kHz
โข Computer Interface: USB 2.0 compliant, Windows, Linux or Mac OS computers with class compliant USB support
โข Chassis Type: All steel black finish
โข Power Requirements: 5.0V DC @
